Home /Products/Through Hole Slip Ring/ABS Engineering Plastics/Mass Production Foundry Manufacturing OEM Moble Aluminum Material Cable Reel With Slip Ring

ABS Engineering Plastics/Mass Production Foundry Manufacturing OEM Moble Aluminum Material Cable Reel With Slip Ring

1.0 piece
MOQ
ABS Engineering Plastics/Mass Production Foundry Manufacturing OEM Moble Aluminum Material Cable Reel With Slip Ring
Features Gallery Product Description Request A Quote
Features
Specifications
Model Number: Customized
Type: Cable Reel With Slip Ring
Product Name:: Foundry Fabrication OEM Moble Cable Reel With Slip Ring
Slip Ring Internal Diameter:: 100mm
Outer Diameter:: 200mm
Ring No.:: 6wires
Signalring Current:: 10A X6wires
Voltage:: 380VAC/240VDC
Speed(rpm):: 0-800rpm/min
House Material:: ABS Engineering Plastics/Aluminum Material
IP Degree:: IP51
Lead Type:: Colour Coded, Silver Plated, PTFE Insulated Lead Wires
Basic Infomation
Model Number: customized
Payment & Shipping Terms
Packaging Details: Mass Production Foundry Fabrication OEM Moble Cable Reel With Slip Ring 1 pcs in a gift box For Electrical Slip Ring , or as customized design package.
Supply Ability: 10000 Piece/Pieces per Year of cable reel with slip ring
Product Description
Through hole slip ring also called hollow slip ring with centre hole,it could be applied to any devices where requires to transmit power and signals when need 360° roating.
Product Description

Features:

1.Standard, off-the-shelf 2.Support power,signals transmitting 3.Advanced multi-point contact brush technology ensures reliable contact with low friction; 4.Gold plated ring and Gold alloy brush 5.Metal housing for better protection; 6.Integrated structure design, easy installation. 7.Customizations acceptable for circuits no. , current& voltage based on standard models; 8.Designed for through bore hydraulic or pneumatic rotating shaft installation.
Specification
Product Name:
Mass Production Foundry Fabrication OEM Moble Cable Reel With Slip Ring
Model
length
Rated Current
Total No.of Circuits
Model
length
power(10A、15A)
signal（2A)
SPR100200-6P
93.5
6
--
6
SPR100200-10S
113.5
--
10
10
SPR100200-12P
96.5
12
--
12
SPR100200-6P/10S
143.5
6
10
16
SPR100200-20S
163.5
--
20
20
SPR100200-18P
153.5
18
--
18
SPR100200-12P/10S
173.5
12
10
22
SPR100200-6P/20S
193.5
6
20
26
SPR100200-30S
213.5
--
30
30
SPR100200-24P
183.5
24
--
24
SPR100200-18P/10S
203.5
18
10
28
SPR100200-12P/20S
233.5
12
20
32
SPR100200-6P/30S
243.5
6
30
36
SPR100200-40S
273.5
--
40
40
SPR100200-30P
213.5
30
--
30
SPR100200-24P/10S
233.5
24
10
34
SPR100200-18P/20S
253.5
18
20
38
SPR100200-12P/30S
273.5
12
30
42

Custom Options

Current,rated voltage,rated speed，temperature，Luton,shell material and color，shape size，special wire，wire length，direction of export，protection grade，terminal type
Max 96 Circuits available on request
TECHNICAL ARAMETERS
Electrical Data
Value
Power
Signal
Nominal Voltage:
380VAC
240VAC/VDC
Insulation Resistance:
≥1000MΩ/500VDC
≥500MΩ/500VDC
Conductor Size:
AWG16 Tin-plated Teflon or PVC insulation Wires
AWG16 Tin-plated Teflon insulation wires
Conductor Length:
Standard 300mm
Insulation strength:
500VAC@50Hz 60s
Electrical Noise:
<0.01Ω
Mechanical data
Value
Working Speed
0-800rpm(or higher)
Working Temperature
-20℃-+80℃ or -40℃-+80℃
Working Humidity
60%RH or higher
Contact Material
Noble Metal
Casting Material
Industrial Metal
Operating Torque
0.1N/m for 6 rings, the torque increases with each 6 rings
Protection Class
IP51
Fully meet the 360-degree unrestricted rotation of power, control and digital signal mixed transmission;Using advanced fiber brush technology, maintenance-free, no lubricating oil;Multi-point contact in each link, low contact pressure, low noise and low contact wear, long service life; standardized, modular design, complete product specifications, and can tailor the products required by customers.
Details Images
Outline Dimension

Typical Applications:

Industrial machine-machining centers,rotary index table,heavy equipment turrets，cable reesl,test equipment，packaging equipment，palletizing machines,magnetic cluth,process equipment,raotary sensors，emergency lighting，robitcs;exibit display equipment,medical equipment
Installation Instructions
Company Profile
Shanghai Matech Machinery Manufacturing Co. Ltd with brand of SAFEPOWER , New Development slip rings & rotary joints manufacturing, performing in aerospace and military applications.

These products are developed for high performance environments and flexible requirements.
Typical applications include camera systems, robotics, packaging machines, medical equipment and a wide range of automation systems.we have experience with a wide variety of designs and applications.

Mounting options include, but are not limited to, end-of-shaft, over-the-shaft and inside-the-shaft mounting. slip rings are manufactured using the highest quality materials available including solid coin silver rings, gold-gold contact, graphite and silver brushes, stainless steel, and aluminum alloys.

Safepower uses state of the art CNC machines to manufacture all of our parts and an experienced workforce to assemble each slip ring.
Customer Photos
Packaging & Shipping
FAQ
Q1.What technical data should be provided for our customized slip ring model.
A:If you want to costomize the special slip ring model, you need provide details as below:
a.operatring speed(RPM) b.the type of installation c.outline size d.channels(the No. of single wire besides cable) e.rated voltage & current for power rings and signal rings f.the signal type and related parameters(very important) g.operating temperature h.IP(sealing requirements)

Q2.How long is your production lead time?
A: It needs 7 to 15 days for standard products, 10 to 20 days for simple customized products,15 to 40 days for complex customized porducts.

Q3: How many types of the slip rings do you have?
A: We can supply all kinds of the slip rings.Such as minitary slip ring,customized sliring,miniature slip ring,fiber optical slip ring,RF rotary joint,HD combined-type,disc slip ring,wind power slip ring,solar power slip ring,through-bore slip ring, etc.

Q4: Can you supply the slip rings with high frequency signals and(or) optical communication signals.
A: Yes, we can supply mixed signals slip rings as your request.

Q5: what's the working life of your slip rings.
A: 30~50 millions revolutions for standard ones, 50~80 millions revolutions for special ones,We also can supply much higher revolutions as your special requirement.
